Fittings TA 220020

Drain Outlet

G 1/2” drain outlet, the smallest of the range. Height 43 mm, length 48 mm, diameter 38 mm, bore E 14 mm. The male thread passes through the tank wall and is secured with a wing nut (listed as TA 205202). Used as a tank drain or a small take-off for a return or agitation line.

Specifications

h	43 mm
L	48 mm
D	38 mm
E	14 mm
M	G 1/2”
Wing Nut Code	TA 205202
